Functional features:
- The sawing machine adopts safe power supply, the body has no plastic parts, and the stability and durability of the equipment are greatly improved.
- The saw blade auxiliary device can greatly prolong the service life of the saw blade and make the use process easier.
- After special design, the Sawtooth will only cause slight vibration when touching the skin, which is safe and does not hurt the hand
- The maximum cutting depth is 4mm for hardwood, 7mm for plywood, 18mm for cork, 0.5mm for thin aluminum sheet and 2mm for plexiglass,
- It can cut straight lines and curves arbitrarily. It is a good helper for students to make models.
- Processing materials: thin aluminum sheet, plexiglass board, wood board and KT board
- Application: the function of cutting and cutting. The main processing material is plywood. It can cut any curve. The operation is flexible and safe without hurting hands. It is a good helper for students to make models.
- Campus maker, labor technology, metalworking and woodworking, high school general technology, comprehensive practice and other internal and external institutional courses and personal DIY.
Technical parameters:
Motor speed: 20000r / min ± 15%
Spindle speed: 3000r / min ± 15%
Voltage / power: 100v-240v, 24W (36W, 60W optional) the motor and spindle box are of metal integrated structure
Workbench area: 100mm * 120mm
Package size: 320mm * 195mm * 340mm
Weight: 3kg
Package Included:
1 × Sawing Cutting
1 × power cable
1 × Single head switching power supply
1 × Thin double-ended wrench
1 × Allen wrench
1 × Double hole slot nut
1 × M4*16 screw
1 × M2*10 screw
1 × saw blade
1 × Small Phillips screwdriver
1 × Phillips medium screwdriver
1 × apron
1 × safety glasses
1 × Bottom plate
