2KW 50~60Hz Swimming Pool Heater Electric Heating Thermostat Water Heater for Swimming Pool SPA Bath 220V

Overview:

• This thermostat is designed specifically for the swimming pool, the thermostat is installed in the pipeline. When adding hot water bath, start the pump, the thermostat automatically heat insulation work, so the water temperature bath maintained at 39 degrees Celsius, give your Swimming Pool to create a more comfortable environment.

• Users should be done after the installation is complete, the first under the premise of safety checks to ensure that the operation of the thermostat's normal function,By using the tub filled with water to a suitable level and start the system automatically checks and let the system run until the thermostat temperature stabilized at the highest level and display lights go out, use an accurate thermometer to measure the water temperature should be at 40 °C.

Main Features:

• Ultra-high temperature (over 49 °C), ultra-high temperature switch will automatically trip (power off)

• Automatic heating: thermostat will first reach the preset temperature, then stop working until the temperature dropped a few degrees, the thermostat automatically turns on

• The thermostat can be maintained within a temperature not exceeding 40 °C (104 °F) range. If cold water is started, will be 6 ~ 8 °C / h elevated temperatures

• COASTS thermostat operation is fully automated, clockwise, the heating is on, indicator light, temperature reaches a preset temperature, will remain at that temperature

• The initial set temperature settings: COASTS equipped with ultra-high temperature protection thermostat switch, thermostat to limit overheating and protect users against danger

How to choose pool heater?

• 1.One cubic meter of water required thermostat 1.5kw-3kw.

• 2.If swimming pool indoor, and ambient temperature is high, the parameter multiplied 1.5kw.

• 3.If the pool is outdoor, or the ambient temperature relatively low , the parameter multiplied 3kw.

• 4.If unable to determine,the parameter multiplied 2kw.

Specifications:

• Input voltage: 220V -240V.

• Size: 18 * 12.5 * 12.5CM/7.08*4.92*4.92IN.

• Power: 3KW.

• Current:13.6A.

• Frequency: 50/60Hz.

• Phase parameters: Single phase.

• Intake: 50mm, outlet: about 32mm.

Pls Note:

• 1. Thermostat outlet to the bath tub in the middle of the pipe or valve or check valve can not be installed.

• 2.This item needs to be wired up to a new plug. Please ensure water pressure is enough to make it work .

• 3.If the power of pump is 500watt better. The water of pool not exceeding 3m³.

Package Included:

• 1 x Water Heating Thermostat .

• 2 x Interface .

• 1 x User Manual.
